Double-head screw fully automatic stamping and rubbing machineLet me tell you that this product buckle machine is widely used in the binding and rivet of luggage, belts, clothing and leather goods, stationery and lighting, especially tents and rain gear.

Performance Features:

1,Straightening and cutting teeth rubbing machineLet me tell you that our factory’s buckle machine has a novel style, compact structure and reasonable structure; the buckle machine is easy to maintain and operate.

2. The buckle machine has output setting and automatic control function (automatic shutdown from the output to the set value), and has a hand-rotating function, adjustment and mold testing, which is more convenient to use a gear-type thimble mechanism. Its material pushing (demolding) is safe and reliable, and can be divided into multiple stages of material pushing.

3. The hand-crank pump can supply oil to all lubrication points, which is convenient to lubricate and has good effect. It uses a gear transmission line, and its conveying line length is accurate, easy to operate, and easy to adjust (set).

4. The buckle machine is advanced, stable, reliable, fast, and has high accuracy. It changes the transmission method (chain type) of the previous traditional buckle machine. All of them are gear transmission, with high transmission efficiency, low power loss and good self-locking performance. It can avoid the loosening of the slide due to the chain being stretched and causing the accuracy to decrease. The friction-type wire feeding mechanism is used to send the wire, and its locking (clip line) action is reliable. The length of the wire feeding is adjusted by fine-tuning, and its length is accurate and high speed is convenient.

5,Guangdong dental rubbing machineLet me tell you that the large gears are made of pearlescent ductile iron (QT600-3) and are heat-treated, and their hardness is: HB280-320. The guide rails are made of alloy wear-resistant cast iron and are heat-treated, and their wear-resistant properties are good. The gears are made of 40Cr forged, and are tempered and treated with high (medium) frequency quenching. The hardness reaches HRC52-55. The shafts use 45 or 40Cr steel and are tempered, and their comprehensive performance is high. The wire conveying wheels and straightening wheels are all made of high-quality alloy steel, and are vacuum heat-treated, and their hardness reaches HRC58-62. It has high strength and good wear-resistant properties.

6. The materials used for the buckle machine are excellent, the processing and heat treatment process are reasonable, and the parts have high comprehensive mechanical properties and long service life.
